Navaid Energy Private Limited |
LED Lighting Systems
LED Flood Lights
NavAid Energy LED Flood Lights are in Multi LED Chip model comes is two range Platinum Series and Diamond Series starting from 50W to 200W with 2years warranty save energy upto 50% on exiting Lighting fixtures.
Why to Choose NavAid LED Flood Lights-
Why to Choose NavAid LED Flood Lights-
- Having Wide range of wattage selection 50W to 200W in NavAid Flood Light housing
- Lumen package ranges from 4,700 to 19,000+ with efficacies of 80-100 lumens per watt
- Effectively replaces retro fitted lighting products from 70-400W minimum
- 6000K Cool white is standard, 4000K natural white is available
- Minimum 80 CRI
- Fixtures are IP66 rated and suitable for use in ambient from -40°C to 40°C
- Rated system life of 80 - 100K hours for the driver
PLATINUM MODELS-(Without Lens)
Model Name |
Wattage |
LED Type |
Lumens |
Dimension |
Weight |
Warranty |
Standard Packing |
LFL-49LED |
50W |
1.5WLED |
5200 |
350x240x65 |
3.5kg |
2years |
3Nos |
LFL-63LED |
60W |
1.5WLED |
6200 |
350x240x65 |
3.5Kg |
2years |
3Nos |
LFL-70LED |
70W |
1.5WLED |
7200 |
350x240x65 |
3.5Kg |
2years |
3Nos |
LFL-70LEDA |
90W |
1.5WLED |
8700 |
350x240x65 |
3.5Kg |
2years |
3Nos |
DIAMOND MODELS-(With Lens)
Model Name |
Wattage |
LED Type |
Lumens |
Dimension |
Weight |
Warranty |
Standard Packing |
LFL-24LEDLENS |
50W |
5W LED |
6000 |
350x240x65 |
3.5kg |
2years |
3Nos |
LFL-36LEDLENS |
90W |
5W LED |
10200 |
350x240x65 |
3.5Kg |
2years |
3Nos |
General Electrical Parameters-
- Efficiency- >85%
- Power factor- >0.9
- Voltage Range- 145-270VAC
- Surge Protection- 4KV Inbuilt
- Open circuit Protection
- 2year warranty
- SPD 10KA (provided with 70W above models)
General Mechanical Parameters-
- Aluminum Die cast body
- Toughened Glass front cover
- Cable Gland for wire entry
- Silicone based gasket for longer life
- Inbuilt Reflector
Test Certificates-
- ISO9001:2008 Quality Test
- CE-13035
- IEC 61000-4-2 (Electrostatic Discharge Immunity)
- IEC 61000-4-3 (Radio Frequency. Electromagnetic Filed Immunity
- IEC 61000-4-5 (Surge immunity)
- IEC 61000-4-6 (Electromagnetic Compatibility Immunity EMC)
Approval-
- NSIC-MSME
