LED STREET LIGHTS

Why to Choose NavAid Energy LED Street Lights

  • Having Wide range of wattage selection 12W to 300W in NavAid Street Light housing

  • Lumen package ranges from 1,100 to 12,100+ with efficacies of 80-100 lumens per watt.

  • Effectively replaces retro fitted lighting products from 70-250W minimum

  • 6000K Cool white is standard, 4000K neutral white is available

  • Minimum 80 CRI

  • Fixtures are IP66 & IP67 rated and suitable for use in ambient from -40°C to 40°C

  • Rated system life of 80 - 100K hours for the driver

  • 2 year limited warranty

  • Powered by Pyrotech LED Driversh

LED STREET LIGHTS

Model NO Wattage LED Type Lumens (Max) Dimension (mm) Weight Warranty
LNEST-9-25W 10-25W 5W 2800 340x134x40 1.6Kg 2year
LNEST-30-45W 30-45W 5W 4900 407x180x45 2.0Kg 2year
LNEST-50-80W 50-80W 5W 5500 455x158x45 2.5Kg 2year
LNEST-90-120W 90-120W 5W 14400 490x170x45 3.5Kg 2year
LNEST-130-150W 130-150W 5W 18000 620x345x70 6.9Kg 2year
LNEST-180-200W 180-200W 5W 18000 620x345x70 7.5Kg 2year


Electrical Parameter

  • Efficiency- >85%
  • Power factor >0.9
  • Voltage Range- 145-270VAC
  • Surge Protection- 4KV
  • Open circuit Protection

B. General Electrical Parameter

  • Aluminum Die cast body
  • Toughened Glass front cover
  • Cable Gland for wire entry
  • Silicone based gasket for longer life
  • Inbuilt Reflector

Test Certificates-

  • ISO9001:2008 Quality Test
  • CE-13035
  • IEC 61000-4-2 (Electrostatic Discharge Immunity)
  • IEC 61000-4-3 (Radio Frequency. Electromagnetic Filed Immunity)
  • IEC 61000-4-5 (Surge immunity)
  • IEC 61000-4-6 (Electromagnetic Compatibility Immunity EMC)
  • IP66/67 Tested as Per IEC 60529

Our LED STREET LIGHTS
