70WATT ALL IN ONE SOLAR STREET LIGHT

Solar Panel

  • 165Wp Poly Perc (Voc-23V)
  • Certification: IEC61215 & IEC61730-1 or BIS approved
  • A-grade Cells will be used (Made in India)

Battery

  • 78Ah 12.8V LiFePO4 (Lithium Ferro Phosphate)
  • Inbuilt BMS for battery health monitoring with temperature compensation
  • BIS Approved and IEC tested (Made in India)

All-in-One Solar LED Light with MPPT Controller

  • Light works with Motion Sensor
  • 70Watt (+10%) All-In-One Integrated Solar LED Street Light
  • Inbuilt MPPT Controller
  • Lumens per watt: >145lm/W
  • 48 Nos 5050 BridgeLux LED used
  • Dusk to Dawn operation
  • Aluminum Housing, IP65 rating
  • Metal IP67 grade Switch
  • Color: White
  • Secondary Optics: Khatod/Ledil make
  • NE logo (Make: NavAid Energy, Made in India)
  • Overall Dimension: 1500x680x55mm

Light Intensity Steps

  • Step 1: 180 Min, 100% Intensity
  • Step 2: 240 Min, 50% Intensity
  • Step 3: 300 Min, 30% Intensity

Indicators

  • Green Blinks: When battery charge is in progress
  • Green Stationary: When battery full charge cut by MPPT
  • Red Stationary: When battery low voltage cut-off ON
  • Green-Red Blinks Together: Error Indicator
  • Green-Red Stationary Together: LED Load Wiring wrong

Protections in MPPT Controller

  • Reverse Polarity
  • Deep Discharge
  • Overcharge
  • No Load
  • Overload
  • Short Circuit
  • Temperature Compensation

System Warranty / Guarantee

3 Years after delivery
