60WATT ALL IN ONE SOLAR STREET LIGHT

Solar Panel

  • 125Wp Mono PERC
  • Certification: IEC61215 & IEC61730-1 or BIS approved
  • A-grade Cells will be used
  • Made in India

Battery

  • 42Ah 12.8V LiFePO4 (Lithium Ferro Phosphate)
  • Inbuilt BMS for battery health monitoring with temperature compensation
  • BIS Approved
  • IEC Tested
  • Made in India

All in One Solar LED Light with MPPT Controller

Light Working with Motion Sensor

  • 60Watt (±10%) ALL In One Integrated Solar LED Street Light with inbuilt MPPT Controller
  • Lumens: >6500lm, 5050 BridgeLux LED Used
  • Dusk to Dawn, Aluminum Housing, IP65
  • Metal IP67 grade Switch, Color: White
  • Secondary Optics: Khatod/Ledil make
  • Motion Sensor: Panasonic make
  • Make: NavAid Energy, Made in India
  • Overall Dimension: 1300x550x55mm

System Warranty/Guarantee

2 YEAR AFTER DELIVERY

Light Intensity Steps with Motion Sensor

  • Step 1: 60Min, 100% Intensity to 20% with Motion Sensor
  • Step 2: 180Min, 50% Intensity to 20% with Motion Sensor
  • Step 3: 300Min, 30% Intensity to 20% with Motion Sensor
  • Step 4: 180Min, 10% Intensity

Indicators

  • Green Blinks: When battery charge in progress
  • Green Stationary: When Battery full charge cut by MPPT
  • Red Stationary: When battery low voltage cut-off ON
  • Green-Red Blinks Together: Error Indicator
  • Green-Red Stationary Together: LED Load Wiring wrong

Protections in MPPT Controller

  • Reverse Polarity
  • Deep Discharge
  • Over Charge
  • No Load
  • Overload
  • Short Circuit
  • Temp. Compensation
