Solar CFL Home Lighting Systems
The Solar CFL Home Lighting System is deigned to provide uninterrupted light by the use of Solar Energy in remote areas where power supply is not available during night time. It aims to provide light by means of CFL Luminary. The system provides 3 days of autonomy. Even additional feature such as Fan (D.C), Television (D.C.) can also be run by this system. As-per MNRE specifications daily usage cycle of 4 Hours only.

Duration of Work
Model-C1 - 3-4 hours daily
Model-C2 - 3-4 hours daily
Model-C3 - 3-4 hours daily

General Electrical Specifications
Max Charging current- 6A
Max. Load current- 6A
Load disconnect battery voltage- 11 ± 0.2 volts or as required
Load reconnect battery voltage- 12.5 ± volts or as required
Constant Charging Voltage- 14.5 ± 0.2 volts or as required
Idle current consumption- Less than 10ma
Light Output- 600 lumens (each 9W CFL) and 900 lumens (each 11W CFL)





















General Technical Specifications
Model Luminary &
Fan (D.C) 		Battery Solar Panel Charge Controller Accessories
NESHLC1 9W or 11W/12V- 1No. 20Ah/12V- 1No. 18W/12V-1No. 6A-1No. Solar module mounting frame, battery box, wire- 14mtr etc.
NESHLC2 9W or 11W/12V- 2Nos. 42Ah/12V- 1No. 37W/ 12V-1No. 6A-1No. Solar module mounting frame, battery box, wire- 14mtr etc.
NESHLC3 9W or 11W/12V- 2Nos. Fan- 18W/12V- 1No. 75Ah/12V- 1No. 74W/12V- 1No. 10A-1No. Solar module mounting frame, battery box, wire- 14mtr etc.
